Description

Cudy’s CD-GS105P is a 5 Port Gigabit switch with 4x 802.3af/at PoE ports, 1x Gigabit Uplink port and a 31W PoE Budget. Both VLAN and Extender modes are supported with the integrated toggle switch. VLAN mode enables port isolation on ports 1-4, while Extender mode increases the transmission distance on ports 1-4 to 250m at 10Mbps. The watchdog function continuously monitors PoE connections when enabled. If an error is detected on the device, the switch immediately restarts the port. The unit features a PoE Max LED that blinks at 90% usage and stays solid at 95%. A PoE LED button lights per-port LEDs to indicate active power delivery.

Specifications:

• Ethernet Ports: 5x 10/100/1000
• Hardware Button: VLAN; Extender; Watchdog
• Max. Power Consumption: 5W
• Mounting: Desktop
• Operating System: None
• Operating Temperature: 0°C to 40°C
• PoE Input: None
• PoE Output: 802.3af/at PoE on Ports 1~4
• Power Input: 1x 54V 0.66amp PSU (Included)
• Serial Interface: None
• SFP Ports: None
• Supported Voltage Range: 100-240V

Dimensions: 119 x 85 x 28mm
Weight: 254g
